Polypropylene Plastic Pall Ring Filler Packing For Rectification
Towers
Product Description
The stainless steel ball ring packing is made of metal sheet, and
two rows of window holes with inner tongue are opened on the ring
wall. Each row of window holes has five tongue leaves, each tongue
leaf bends into the ring, points to the ring center, almost phase
tower in the center, the upper and lower two layers of window holes
are staggered with each other, generally the total area of the
opening is about 35% of the whole ring wall area, so that the gas
and liquid in the tower can freely pass through the window. At
present, Bauer ring packing is still one of the main ring packing
used.
Product Feature
1. Beautiful shape, almost no burr.
2. Good structure, it has the advantages of high flux, low
resistance, high separation efficiency and large operating
flexibility.
3. 100% virgin material: PP, ensure the product is endurable and
safe.
4. Wide range of application, can be used in many industrial
fields.
5. Large void ratio, low pressure drop and mass transfer unit
height, high flooding point, sufficient gas-liquid contact, small
specific gravity, high mass transfer efficiency
Product Application
Suitable for carbon dioxide degassing tower, ozone contact reaction
tower, etc. as contact packing and other reaction towers.
PP Pall ring is especially suitable for middle and low temperature
(60-80 °) distillation , absorb for petroleum, chemical industry,
chlor alkali, gas, environmental protection and other industries.
It is also suitable to be contact packing for absorption and
washing tower, carbon dioxide degassing tower / ozone contact tower
and other reaction towers;
Technology Parameter
Model (mm) | Material | Diameter×Height ×Thickness (mm) | Surface area (m²/m³) | Void space% | Bulk density (kg/m³) | No.elements (n/m³) | Packing factor m-1 |
| Φ25 | Plastic | 25×25×1.2 | 213 | 91 | 85 | 48300 | 285 |
| Φ38 | Plastic | 38×38×1.4 | 151 | 91 | 82 | 15800 | 200 |
| Φ50 | Plastic | 50×50×1.5 | 100 | 92 | 60 | 6300 | 130 |
| Φ76 | Plastic | 76×76×2.6 | 72 | 92 | 62 | 1930 | 92 |
