60mm Three-dimensional Elastic Filler For Aerobic And Anaerobic
Tank
Product Description
HUISEN Elastic Filler choose good material which is resistant to
corrosion, temperature and aging and use special craftsmanship to
insert and fix the plastic silk on the central rope, so it has
corrosion resistance and high strength. Due to the excellent
material selection and craftsmanship, the wire is rigid and soft,
which makes the elastic filler uniform arrangement and radiation.
The filler can be evenly spread in all directions in the effective
area, so that the air, water and biofilm can be fully infiltrated
and contact exchanged. The biofilm can not only be evenly implanted
on each filament, maintain good activity and space variability, but
also obtain more and more specific surface area in the operation
process, and can be carried out Good metabolism.
In the operation the gas is driven by three - dimensional flow of
sewage, colliding with each other and being continuously cut by the
spiral net to form microbubbles, that increase the utilization of
oxygen and reduce the air.At the same time, the biofilm can have a
good metabolism effect not adhesion.
Product Features
* Strong bubble cutting ability;
* Large space volume utilization;
* Non blind-aera, difficult to plug;
* Easy to assemble, no need to use rope network to intercept and
divide the pool body, just need fix the up and down grille.
Technology Parameter
Model (mm) | Unit Length (m/m3) | Unit Weight (kg/m3) | Film Weight (kg/m3) | Surface Area (m2/m3) | Wire Diameter (mm) |
| φ150 | 44 | 2 | 69 | 310 | 0.45 |
| φ160 | 39 | 1.9 | 66 | 280 | 0.45 |
| φ180 | 30 | 1.8 | 62 | 265 | 0.45 |
| φ200 | 25 | 1.7 | 60 | 250 | 0.45 |
Working Principle
1m3 elastic filler contains 44meter valid length, when customer
purchase, should tell us the length of the frame, such as 1m, 1.5m,
2m, so that we can cut the elastic filler to this length and leave
enough invalid length to tie the filler on the frame.
When elastic filler is fixed on the frame, and put into waste
water, after few days, biofilm will incur and start to treat the
waste water by using microorganism.
